Nivel System CL4D-B

2 vertical, 2 horizontal planes, extra fine blue beam

The Level System CL4D-B laser level is an excellent choice for construction professionals who require a high-precision, rugged and versatile tool. This model provides a complete solution for any project, ensuring fast, accurate and efficient measurements.


Nivel System CL4D-B – the multi-purpose 4D cross laser with the superb blue laser beam (505 nm). Perfectly levelled reference lines (horizontal and vertical, each in the range of 360°), are projected on surfaces by the four laser heads.

Exceptionally low horizontal line (only 20 mm above the floor level) is a great aid in construction and finishing works (e.g. tiling).

The electronic compensator provides a very high accuracy (±1 mm/ 10 m), which is indispensable for applications that require the highest precision.

Quick self-levelling and much more efficient vibration damping with no beam-swing effect is achieved with an excellent electronic compensator. While the compensator locked the unit can also be tilted, thus work in slant planes. The built-in 1/4″ thread enables steady fastening the equipment to a tripod, adapter or laser shelf. The unit is very well protected against dust and water under the IP54 rating. The leaser heads are protected by the metal shields whereas the glass windows have anti-reflective filters- the laser beam does not reflect from the glass and no laser glows are formed. The rubber protectors at the corners of the device body prevent from abrasion as well as provide a better grip.


• accuracy and reliability – fine beam of the blue laser guarantees comfortable work in all conditions, the unit enables work with the accuracy of ± 1 mm / 10 m

• even greater range – with pulse function and the sensor you can use the laser at large distances for outdoor applications

• precise beam projection – very clearly visible lines generated by bright blue laser beam and high-quality optics

• versatility and multitasking – 4 laser planes (360 °)

• quick and efficient levelling –innovative electronic vibration compensation system ensures a quick preparation of the unit for work, the laser precisely sets the beam, even on an unstable base, as well as allows to work with slant planes after locking of the compensator

• intuitive operation – easy and quick to use

• laser adapter and elevator – secure fastening even in difficult conditions on the site and fine height adjustment

• convenient power supply – Li-ion pack with the backup battery

• resistant to damage and wear– the equipment is resistant to dust and water (IP54), rubber parts of the laser housing protect it from impact or shock damage

Accuracy and Performance

The Laser Level System CL4D-B redefines the standard in precision measurement, offering an impressive accuracy of ±1 mm at 10 m. Equipped with a highly visible blue laser beam, this instrument is ideal for work requiring extreme accuracy over distances of up to 70 m with a detector.



Durability and Reliability

Designed to withstand tough site conditions, the CL4D-B is protected against dust and water splashes with an IP54 rating. The reinforced housing ensures long-lasting durability even in demanding working environments.



Flexibility in Use

The instrument has four laser planes (two horizontal and two vertical) covering a 360° range, allowing the user to perform complex measurements without the need for frequent reconfiguration. The compensator lock function allows the laser to be used in tilted mode for special applications.



Connectivity and Ease of Operation

Equipped with Bluetooth technology, the CL4D-B allows control from mobile devices via a dedicated app, making it easy to manage settings quickly and efficiently. It comes equipped with an intuitive control panel and an LED display indicating battery charge level and function status.



Full Package

The package includes the CL4D-B laser unit, construction and floor laser targets, laser lift, adapter, rechargeable Li-ion batteries, charger, laser visibility goggles, and a carrying case for easy on-site maneuverability.






Technical specifications
